GTV Banner

Gate
Ticket Validator

Flownex CTV Prime

Flownex GTV
Flownex GTV

Flownex CTV Prime

Flownex CTV Prime is an advanced gate validator platform, purpose-built for metro access control, delivering fast, secure, and seamless contactless payment processing with robust security features.

LEARN MORE

Features


High Resolution Colour Graphical Display


Fully Programmable User Interface


Multilanguage Support


EMV Level 1, 2 & 3 Certified Contactless Card Reader


Buy America America-compliant device


High Speed SAM Controller


High Performance 2D Image Engine able

Parallax Image

I/O Module

Specification

Software Platform Linux, Android 12
Processor Quad-Core core Cortex-A55 @ 1.8GHz
RAM 2GB LPDDR4 / LPDDR4X
Storage 8GB flash
Display 7” color LCD panel (720 x 1280)
Card Readers Contactless NFC contactless: ISO14443 A & B, MIFARE, Sony Felica
Barcode Scanner High Performance 1D/2D Barcode Scanner Engine
Ethernet 1 x 10/100/1000Mbps
COM Ports 1 x RS232
USB 2 x USB-C Host and OTG
GPIOs
  • 2 x Isolated Digital Input
  • 4 x Isolated Digital Output
Audio 1.3W@8 ohm Speaker output
Power Input 9-36 VDC, 2A
Environmental
  • Operating temperature: -20°C~60°C (-4°F~ 140°F)
  • Storage temperature: -20°C~70°C (-4°F~ 158°F)
  • Relative humidity (non-condense): 5% ~ 95%
Dimensions 400 mm (L) x 140 mm (B) x 70 mm (W)
DOWNLOAD
BROCHURE
