Onboard Managed
Ethernet Switch



Flownex-MSW10 is a managed POE Ethernet switch ideal for rail and automotive applications. They are equipped with high quality M12 connectors. Flownex-MSW10 offers management functionality to realize network segmentation and redundant ring topology networks. It is designed in a metal housing to reach the protection class of IP54 with wall mounting feature. The ethernet switch provides 10 ethernet M12 ports; 8 ports support IEEE 802.3at/af compliant PoE functionality.



Multilayer Switch

POE management

Wide operating voltage range

Remote device management platform

Supports harsh environments and industrial conditions

Parallax Image

I/O Module



1 Gb
Uplink Port

1 Gb
Downlink Port

PoE FE Ports

PoE FE Ports


  • IEEE 802.3u 10Base-T Ethernet
  • IEEE 802.3u 100Base-TX Ethernet
  • IEEE 802.3ab 1000Base-TX Gigabit Ethernet
  • IEEE 802.3af Power over Ethernet
  • IEEE 802.3at High Power over Ethernet
  • IEEE802.3x Flow Control and Back Pressure
  • IEEE802.3ad Port trunk with LACP
  • IEEE802.1d Spanning Tree
  • IEEE802.1s Multiple Spanning Tree
  • IEEE802.3ad Link Aggregation Control Protocol (LACP)
  • IEEE802.1AB Link Layer Discovery Protocol (LLDP)
  • IEEE802.1X User Authentication (Radius)
  • IEEE802.1p Class of Service
  • IEEE802.1Q VLAN Tag
Switch Architecture Non-blocking eight traffic class QoS switch fabric
Mac Address 16K
Jumbo frame 10K Bytes
Ethernet Ports 2 x 1000 Base-T/ Gigabit Ethernet port for uplink and downlink with bypass enable: M12-X code 8-pin female connectors 8 x 100 Base-T/ Fast Ethernet ports : M12-D code 4-pin female connectors
LED Indicators
  • Ethernet port: Link/Activity (Green), Speed (Green)
  • PoE: Link/Act (Green, PoE model)
  • Per unit: Power 1 (Green), MOD (Green) ERR (Red)
USB Port OS update
Power over Ethernet IEEE 802.3af/at,End-span wiring architecture
PoE operating mode Auto PoE: IEEE 802.3af/at with 2-event detection for PD
Powering capability IEEE 802.3af : 15.4 W, IEEE802.3at : 30W
PoE system power budget 80 Watt
Power Supply 24V nominal(16.8V-33.6V)
Enclosure Aluminium
IP Rating IP54
Enclosure Dimensions 232.08 x 157 x 85.5 mm including wall mount
Operating Temperature -40°C~85°C
Mechanical IP54
Compliance CE, ROHS, EN50155, EN45545, ITxPT
